Total Carter SH 220

GET A QUOTE

VISCOSITY - ISO 220

Total Carter SH 220 Synthetic Lubricant For Enclosed Gear Drives

DESCRIPTION

Total Carter SH 220 Synthetic Lubricant is especially suited for use in light to heavy-duty gearboxes where gears are subjected to very high loads and high temperatures in difficult environments.

Carter SH has been developed based on PAO (Polyalphaolefin) for enclosed gear drives to provide optimum gear protection against micro pitting and bearing protection against scuffing, under very severe and difficult conditions such as high loads and high operating temperatures.

This lubricant is highly suited lubricant for wind turbine gears.

Not compatible with PAG-based lubricants.

APPLICATIONS

TOTAL CARTER SH 220 has been developed to provide optimum lubrication for enclosed
industrial gears and bearings, and under very severe conditions anti-wear and extreme
pressure protection against scuffing.
– Bevel and spur gears
– Worm gears
– Heavily loaded bearings and gear couplings.

ADVANTAGES

DIN 51517 – 3 CLP
ISO 12925-1 CKSMP
AISI 224
CINCINNATI MILACRON
DAVID BROWN
SIEMENS-FLENDER (VG 150 to VG 680)
USINOR FT 161
MÜLLER WEINGARTEN
AGMA 9005 – E02

TYPICAL CHARACTERISTICS

TYPICAL CHARACTERISTICS	METHODS	UNITS	CARTER SH 220
Density at 15 °C	ISO 3675	kg/m3	859,7
Viscosity at 40 °C	ISO 3104	mm²/s	220,1
Viscosity at 100 °C	ISO 3104	mm²/s	26,2
Viscosity index	ISO 2909	–	152
Open cup flash point	ISO 2592	°C	242
FZG Micropitting	FVA 54 IIV	–	10 +
FZG A/8.3/90	DIN 51 354/2	–	> 13
Pour point	ISO 3016	°C	– 45

APPROVAL & PERFORMANCE CLAIMS

ADDITIONAL INFORMATION

All packages should be stored under cover. Where outside storage is unavoidable drums should be laid horizontally to avoid the possible ingress of water and damage to drum markings. Products should not be stored above 60°C, or exposed to hot sun or freezing conditions.

Product Data Sheet
