Industrial Gear Oils

Total Carter SH 1000
Brand Logo

VISCOSITY - ISO 1000

Total Carter SH 1000 Synthetic Lubricant For Enclosed Gear Drives

open
DESCRIPTION

Total Carter SH 1000 Synthetic Lubricant is especially suited for use in light to heavy-duty gearboxes where gears are subjected to very high loads and high temperatures in difficult environments.

Carter SH has been developed based on PAO (Polyalphaolefin) for enclosed gear drives to provide optimum gear protection against micro pitting and bearing protection against scuffing, under very severe and difficult conditions such as high loads and high operating temperatures.

This lubricant is highly suited lubricant for wind turbine gears.

Not compatible with PAG-based lubricants.



open
APPLICATIONS
  • TOTAL CARTER SH 1000 has been developed to provide optimum lubrication for enclosed
    industrial gears and bearings, and under very severe conditions anti-wear and extreme
    pressure protection against scuffing.
    – Bevel and spur gears
    – Worm gears
    – Heavily loaded bearings and gear couplings.

This lubricant is highly suited lubricant for wind turbine gears.

open
ADVANTAGES

Total Carter SH 1000 Synthetic Lubricant For Enclosed Gear Drives Advantages:

  • Excellent extreme-pressure performance: protection against high loads and micro pitting.
  • Very high natural viscosity index (shear stable) and low friction coefficient providing
    energy saving* up to 4 % compared to mineral oil lubrication.
  • Very low pour point: operation at very low temperatures.
  • Very good oxidation resistance: operation at high temperatures, and lifetime increased
    by a factor of 2 to 4.
  • Compatible with seals and metals containing copper.
open
TYPICAL CHARACTERISTICS
TYPICAL CHARACTERISTICS METHODS UNITS CARTER SH 1000
Density at 15 °C ISO 3675 kg/m3 869,5
Viscosity at 40 °C ISO 3104 mm²/s 997,8
Viscosity at 100 °C ISO 3104 mm²/s 85,6
Viscosity index ISO 2909 169
Open cup flash point ISO 2592 °C 229
FZG Micropitting FVA 54 IIV 10 +
FZG A/8.3/90 DIN 51 354/2 > 13
Pour point ISO 3016 °C – 28
open
APPROVAL & PERFORMANCE CLAIMS
  • DIN 51517 – 3 CLP
  • ISO 12925-1 CKSMP
  • AISI 224
  • CINCINNATI MILACRON
  • DAVID BROWN
  • SIEMENS-FLENDER (VG 150 to VG 680)
  • USINOR FT 161
  • MÜLLER WEINGARTEN
  • AGMA 9005 – E02
open
ADDITIONAL INFORMATION

All packages should be stored under cover. Where outside storage is unavoidable drums should be laid horizontally to avoid the possible ingress of water and damage to drum markings. Products should not be stored above 60°C, or exposed to hot sun or freezing conditions.

Contact Us

Product Data Sheet

Total Energies Carter SH 1000 Transmission Oil
PACK SIZES AVAILABLE
icon
20L
icon
208L

Request a quote for this product
