Agricultural Transmission & Gear Oil

Castrol Transmax Agri Trans Plus 80w
Brand Logo

VISCOSITY - SAE 80

Castrol Transmax Agri Trans Plus 80w Universal Transmission Fluid UTTO

open
DESCRIPTION

Castrol Transmax Agri Trans Plus 80W is an all in one agricultural and off-highway oil that can be used in a number of applications including hydraulic, transmission and PTO of tractors and off-highway equipment. It gives high levels of wear prevention from start-up and throughout the operative period with enhanced corrosion protection properties.

open
APPLICATIONS
open
ADVANTAGES

Castrol Transmax Agri Trans Plus 80w Universal Transmission Fluid Product Advantages:

  • Outstanding wet clutch and wet brake performance
  • One oil reduces inventory, simplifies servicing, avoids misapplication and saves money
  • Longer component life when compared to conventional hydraulic oils reducing downtime and maintenance costs
  • Maintains operating temperature and smoother gear-changing
  • Excellent oxidation stability and anti-corrosion properties
  • Suitable for use in S-Matic CVT and RC-shift transmissions
open
TYPICAL CHARACTERISTICS
Name Method Units Transmax Agri Trans Plus 80W
Density @ 15C, Relative



ASTM D1298 g/ml 0.884
Viscosity, Kinematic 100C



ASTM D445 mm²/s 9.8
Viscosity, Kinematic 40C



ASTM D445 mm²/s 55
Viscosity Index



ASTM D2270 None 161
Viscosity, CCS -25C



ASTM D5293 mPa.s (cP) 6900
Viscosity, Brookfield @ -35C



ASTM D2983 mPa.s (cP) 35000
Pour Point



DIN-ISO 3016 °C -45
Flash Point, COC ASTM D92 °C 232
open
APPROVAL & PERFORMANCE CLAIMS

API GL-4
MF – M1145
Volvo Transmission Oil 97303:053 (WB 101)
ZF TE-ML 03E, 05F, 17E, 21F
Meets Ford ESN-M2C-134D, JD 20C
Suitable for use where Case 1207, Case 1209,
MAT 3505, MAT 3525, MAT 3540,
NH410B or Ford M2C86-B are specified.
Suitable for use in S-Matic CVT and RC-shift transmissions.

open
ADDITIONAL INFORMATION

Storage:

All packages should be stored under cover. Where outside storage is unavoidable drums should be laid horizontally to avoid the possible ingress of water and damage to drum markings. Products should not be stored above 60°C, or exposed to hot sun or freezing conditions.

Contact Us

Safety Data Sheet

Product Data Sheet



Castrol Agri Trans Plus 80w - Agricultural Transmission Oil
PACK SIZES AVAILABLE
icon
20L
icon
208L
